THÉP NHẬP KHẨU CHỮ I

Tên sản phẩm

Thép hình chữ I

Tiêu chuẩn

SS400B TO JIS G3101

Chiều cao thân

100 % 900 mm

Độ rộng cánh

50 % 400 mm

Chiều dài THÉP HÌNH CHỮ H NHẬP KHẨU

6000 % 12000 mm

Kích thước danh nghĩa

Kích thước mặt cắt ngang

KL 1 m chiều dài

Mômen quán tính

Bán kính xoay

Modul tiết diện

H

B

r1

r2

r

W

Ix

Iy

ix

iy

Zx

Zy

mm

mm

mm

mm

mm

mm

Kg/m

cm4

cm4

cm

cm

cm3

cm3

100 X 100

100

100

6

8

10

17.2

383

134

4.18

2.47

76.5

26.7

125 X 125

125

125

6.5

9

10

23.8

847

293

5.29

3.11

136

47.0

150 X 75

150

75

5

7

8

14.0

666

49.5

6.11

1.66

88.8

13.2

150 X 100

148

100

6

9

11

21.1

1,020

151

6.17

2.37

138

30.1

150 X 150

150

150

7

10

11

31.5

1,640

563

6.39

3.75

219

75.1

175 X 175

175

175

7.5

11

12

404

2,880

984

7.50

4.38

330

112

200 X 100

198

99

4.5

7

11

18.2

1,580

114

8.26

2.21

160

23.0

200

100

5.5

8

11

21.3

1,840

134

8.24

2.22

184

26.8

200 X 150

194

150

6

9

13

30.6

2,690

507

8.30

3.61

277

67.6

200 X 200

200

200

8

12

13

49.9

4,720

1,600

8.62

5.02

472

160

*

200

204

12

12

13

56.2

4,980

1,700

8.35

4.88

498

167

*

208

202

10

16

13

65.7

6,530

2,200

8.83

5.13

628

218

250 X 125

248

124

5

8

12

25.7

3,540

255

10.4

2.79

285

41.1

250

125

6

9

12

29.6

4,050

294

10.4

2.79

324

47.0

250 X 175

244

175

7

11

16

44.1

6,120

984

10.4

4.18

502

113

250 X 250

*

244

252

11

11

16

64.4

8,790

2,940

10.3

5.98

720

233

248

249

8

13

16

66.5

9,930

3,350

10.8

6.29

801

269

250

250

9

14

16

72.4

10,800

3,650

10.8

6.29

867

292

*

250

255

14

14

16

82.2

11,500

3,880

10.5

6.09

919

304

300 X 150

298

149

5.5

8

13

32.0

6,320

442

12.4

3.29

424

59.3

300

150

6.5

9

13

36.7

7,210

508

12.4

3.29

481

67.7

300 X 200

294

200

8

12

18

56.8

11,300

1,600

12.5

4.71

771

160

*

298

201

9

14

18

65.4

13,300

1,900

12.6

4.77

893

189

300 X 300

*

294

302

12

12

18

84.5

16,900

5,520

12.5

7.16

1,150

365

*

298

299

9

14

18

87.0

18,800

6,240

13.0

7.50

1,270

417

300

300

10

15

18

94.0

20,400

6,750

13.1

7.51

1,360

450

*

300

305

15

15

18

106

21,500

7,100

12.6

7.26

1,440

466

*

304

301

11

17

18

106

23,400

7,730

13.2

7.57

1,540

514

*

310

305

15

20

18

130

28,150

9,460

13.2

7.60

1,810

620

350 X 175

346

174

6

9

14

41.4

11,100

792

14.5

3.88

641

91.0

350

175

7

11

14

49.6

13,600

984

14.7

3.95

775

112

*

354

176

8

13

14

57.8

16,100

1,180

14.8

4.01

909

134

340 X 250

*

336

249

8

12

20

69.2

18,500

3,090

14.5

5.92

1,100

248

340

250

9

14

20

79.7

21.700

3,650

14.6

6.00

1,280

292

350 X 350

*

338

351

13

13

20

106

28,200

9,380

14.4

8.33

1,670

534

*

344

348

10

16

20

115

33,300

11,200

15.1

8.78

1,940

646

350

350

12

19

20

137

40,300

13,600

15.2

8.84

2,300

776

*

350

357

19

19

20

156

42,800

14,400

14.7

8.53

2,450

809

400 X 200

396

199

7

11

16

56.6

20,000

1,450

16.7

4.48

1,010

145

400

200

8

13

16

66.0

23,700

1,740

16.8

4.45

1,190

174

*

404

201

9

15

16

75.5

27,500

2,030

16.9

4.60

1,360

202

400 X 300

*

386

299

9

14

22

94.3

33,700

6,240

16.7

7.81

1,740

418

390

300

10

16

22

107

38,700

7,210

16.9

7.28

1,980

481

400 X 400

*

388

402

15

15

22

140

49,000

16,300

16.6

9.54

2,520

809

*

394

398

11

18

22

147

56,100

18,900

17.3

10.1

2,850

951

*

394

405

18

18

22

168

59,700

20,000

16.7

9.65

3,030

985

400

400

13

21

22

172

66,600

22,400

17.5

10.1

3,330

1,120

400

408

21

21

22

197

70,900

23,800

16.8

9.75

3,540

1,170

*

406

403

16

24

22

200

78,000

26,200

17.5

10.1

3,840

1,300

*

414

405

18

28

22

232

92,800

31,000

17.7

10.2

4,480

1,530

450 X 200

446

199

8

12

18

66.2

28,700

1,580

18.5

4.33

1,290

159

450

200

9

14

18

76.0

33,500

1,870

18.6

4.4

1,490

187

450X300

*

434

299

10

15

24

106

46,800

6,690

18.6

7.04

2,160

448

440

300

11

18

24

124

56,100

8,110

18.9

7.18

2,550

541

500 X 200

496

199

9

14

20

79.5

41,900

1,840

20.3

4.27

1,690

185

500

200

10

16

20

89.6

47,800

2,140

20.5

4.33

1,910

214

*

506

201

11

19

20

103

56,500

2,580

20.7

4.43

2,230

257

500 X 300

482

300

11

15

26

114

60,400

6,760

20.4

6.82

2,500

451

488

300

11

18

26

128

71,000

8,110

20.8

7.04

2,910

541

600 X 200

596

199

10

15

22

94.6

68,700

1,980

23.9

4.05

2,310

199

600

200

11

17

22

106

77,600

2,280

24.0

4.12

2,590

228

*

606

201

12

20

22

120

90,400

2,720

24.3

4.22

2,980

271

*

612

202

13

23

22

134

103,000

3,180

24.6

4.31

3,380

314

600 X 300

582

300

12

17

28

137

103,000

7,670

24.3

6.63

3,530

511

588

300

12

20

28

151

118,000

9,020

24.8

6.85

4,020

601

*

594

302

14

23

28

175

137,000

10,600

24.9

6.90

4,620

701

700 X 300

692

300

13

20

28

166

172,000

9,020

28.6

6.53

4,980

602

700

300

13

24

28

185

201,000

10,800

29.3

6.78

5,760

722

*

708

302

15

28

28

215

237,000

12,900

29.4

6.86

6,700

853

800 X 300

792

300

14

22

28

191

254,000

9,930

32.3

6.39

6,410

662

800

300

14

26

28

210

292,000

11,700

33.0

6.62

7,290

782

808

302

16

30

28

241

339,000

13,800

33.2

6.70

8,400

915

900 X 300

*

890

299

15

23

18

210

339,000

10,300

35.6

6.20

7,610

687

*

900

300

16

28

18

240

404,000

12,600

36.4

6.43

8,990

842

*

912

302

18

34

18

283

491,000

15,700

36.9

6.56

10,800

1,040

*

918

303

19

37

18

304

535,000

17,200

37.2

6.67

11,700

1,140
